Datalogic QuickScan QW2520 Barcode Scanner (QW2520-BKK11S)

The Datalogic QuickScan QW2500 (corded USB model QW2520) is an affordable 2D handheld barcode scanner that reads 1D and 2D codes from paper labels and from phone screens, with Datalogic's Green Spot good-read confirmation. With its VGA imager and plug-and-play USB connection it is a cost-effective way to bring 2D scanning to retail checkouts and service desks. This black version, QW2520-BKK11S, is supplied with a 2.4 m coiled USB cable and a collapsible stand for hands-free scanning.

Key Features

• Reads 1D and 2D codes – omnidirectional reading of linear, 2D (QR, Data Matrix, Aztec, DotCode), postal, stacked and composite codes, on paper labels and on phone screens – e-coupons, loyalty cards and mobile tickets.
• Cost-effective VGA imager – the 640 × 480 pixel sensor reliably reads 13 mil EAN/UPC codes at up to 40 cm and resolves 1D codes as fine as 3 mil.
• Datalogic Green Spot – a green light projected onto the barcode confirms every good read, even in noisy environments.
• Motionix motion sensing – switches automatically between handheld and presentation (hands-free) reading modes.
• Blue aiming dot and soft red illumination – the precise single-dot aimer makes it easy to pick the right code, and the soft red light reduces operator eye fatigue.
• Plug-and-play USB – USB interface with USB-A or USB-C host cables; easy setup with the free Datalogic Aladdin configuration tool and OPOS/JavaPOS utilities.
• Built to last – withstands repeated 1.5 m drops to concrete, IP52 sealed, trigger rated for 10 million actuations, with a 36-month warranty.

Ideal Applications

• Retail point of sale – check-out, loyalty cards and mobile coupons
• Commercial services – postal, banking, public administration and utilities
• Hospitality, events and transport – checking mobile and paper tickets
• Pharmacies and front desks – prescriptions, documents and ID cards
• Libraries, offices and back rooms – document, asset and stock tracking

All QuickScan QW2520 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Not sure which version you need? If you already have a compatible Datalogic USB cable at the checkout, the scanner-only version is the most economical choice; for a new workstation, pick a USB kit – with a straight or coiled cable, and with the collapsible stand if you also want hands-free scanning. Need an RS-232 interface or Digimarc reading? Take a look at the Datalogic QuickScan QD2500. Compare other models in our Handheld Barcode Scanners collection or contact our team for volume pricing.
