TSC TH340R Desktop Label Printer (TH340R-A001-0222)

The TSC TH340R (TH340R-A001-0222) is a 4-inch desktop RFID label printer that prints and encodes UHF RFID smart labels in a single pass – thermal transfer or direct thermal at 300 dpi and up to 152 mm/s (6 ips), with a max. print width of 105.7 mm. Its built-in RAIN RFID (EPC Gen2) encoder with Encode During Print and auto-calibration makes RFID tagging for retail, logistics and asset tracking simple. A 3.5" colour touch display makes setup and status checks quick. It takes 127 mm label rolls and large 300 m ribbons, speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and a USB host port, plus factory-installed MFi Bluetooth 5.0. A factory-fitted guillotine cutter cuts labels and tags to length. Supplied with power supply, EU power cord and USB cable – ready to print.

Key Features

• Thermal transfer and direct thermal at 300 dpi – up to 152 mm/s (6 ips), max. print width 105.7 mm
• Built-in UHF RFID encoder (RAIN RFID, EPC Gen2 / ISO 18000-63): Encode During Print, automatic RFID calibration and support for a wide range of UHF inlays, including selected on-metal labels
• 3.5" colour touch display (480 × 320) with feed, pause and reprint buttons
• 300 m ribbons on a 1" core (ink outside) for fewer changes; also 110 m ribbons on a 0.5" core, 40–110 mm wide
• 127 mm (5") label rolls on 25.4–38.1 mm cores, media 15–120 mm wide (down to 10 mm with the optional adaptor); fanfold, black-mark and notched media
• TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
• USB 2.0, RS-232, 10/100 Ethernet and USB host plus factory-installed MFi Bluetooth 5.0 for printing from iOS and Android devices
• 128 MB Flash, 128 MB SDRAM, microSD slot (up to 512 GB) and real-time clock
• Remote management via embedded web page, virtual control panel, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
• TPH Care printhead diagnostics, ribbon-low warning and tool-free printhead and platen roller replacement
• Factory-fitted guillotine cutter (full and partial cut)
• Eco design: 100% recyclable packaging and casing made with 30% recycled plastic; 3-year TSC warranty in EMEA

Ideal Applications

• Retail – RFID price tags, apparel hang tags and inventory labels
• Logistics and warehousing – RFID pallet, carton and shipping labels
• Manufacturing – work-in-progress, asset and tool tracking labels
• IT and facilities – asset tags, including selected on-metal RFID labels
• Libraries, events and access control – RFID tags and badges

All TH240R / TH340R RFID Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Need a different resolution, media option or wireless interface? All TH240R / TH340R RFID versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for RFID label advice and volume pricing.
